Mic 18-1 carbonated drink can filling line machine adopts counter pressure filling system which is applicable for beer, carbonated beverage, soft drink, hard cider, soda water, sparkling water and other canned gas drinks (Cold filling temperature at 0-4 degrees Celsius)
If you also want to use the same machine to fill non-carbonated drinks is available. Through change the counter pressure filling valves to normal pressure filling valves then it will be suitable for filling non-carbonated beverages such as energy drink, fruit juice, cold brew coffee, vitamin water, herbal tea and so on.
beer canning machine, beer can machine, beer can filling machine, beer filling machine, canning line, beer canning machine for sale, beer canning line
Machine features:
1. Mic 18-1 carbonated beverage can filling machine is in the digestion and absorption of advanced foreign and domestic sealing machine on the basis of independent development of the can filling, sealing unit. Filling and seaming part is the overall designed, in order to ensure that both the absolute synchronization and coordination.
2. Isobaric filling system, controlled by pressure, accuracy is +/-1%,liquid level difference is not more than 2mm. (requires steady pressure and temperature at 0-4degrees Celsius).
3. Can seaming machine is qualified for Chinese seaming standard, and no air leakage at all.
4. It has the characteristics of filling reposefully, high speed, liquid level control, capping reliably, frequency conversion timing, less material loss. It can equip CIP system according to the customers’ request. It is the preferred equipment for the small brewery and medium beverage plant.
5. Aluminum can and metal can are both available working on our seaming machine, We use our own technical drawing and own processing machine, to make sure our seaming head quality and always easy to purchase.
6. If Cans stock on conveyor then sensor will inform PLC to stop the Can feeding.
In the competitive world of brewing, the efficiency and quality of packaging play a significant role in the success of a brewery. Understanding the nuances of beer packaging machine, beer packaging equipment, and craft beer filling machine is crucial for optimizing production processes and maintaining high standards of product quality.
Beer packaging machine are sophisticated systems designed to automate and streamline the packaging process for beer. These machines handle various tasks such as filling, sealing, and labeling, and are essential for achieving consistent and efficient production. The performance of beer packaging machine is measured by their speed, accuracy, and ability to integrate seamlessly into the production line. Advanced beer packaging machines offer features like programmable settings, high-speed operation, and the capability to handle multiple container types and sizes. This ensures that breweries can maintain high levels of productivity while delivering a high-quality product.
Beer packaging equipment encompasses a broad range of machinery used in the packaging process, from filling stations to labeling and capping systems. The effectiveness of beer packaging equipment is characterized by its ability to handle different types of containers, such as cans, bottles, and kegs, while maintaining precision and hygiene. Modern beer packaging equipment often includes automated features that enhance operational efficiency and reduce manual labor. These systems are designed to accommodate the specific needs of breweries, whether they are producing large volumes or crafting specialty beers, ensuring that every package meets quality standards.
For craft breweries, the craft beer filling machine is a critical component of the packaging line. This machine is tailored to handle the unique requirements of craft beer production, including varying beer styles and packaging formats. The performance of a craft beer filling machine includes accurate filling, minimal foaming, and gentle handling to preserve the beer’s quality and flavor. Unlike high-speed, large-scale filling systems, craft beer filling machine are designed with flexibility and precision in mind, making them ideal for smaller batches and diverse product offerings.
In summary, beer packaging machine, beer packaging equipment, and craft beer filling machine each play a vital role in the brewing and packaging process. By focusing on their performance and features, breweries can select the most appropriate equipment to enhance production efficiency, maintain high-quality standards, and meet the specific needs of their operations.
Inline can rinser / can washing machine
The inline can rinser is used to clean the empty cans by clean water before filling, we can add this can rinser in the beginning of filling line. The twist cages are customized with your sample cans. As long as the height and diameter of your cans are different, you need to buy the extra set twist cages to change.
“MIC” Isobaric pressuring filling does not create foaming during fill, unless beer is above 40°F. Counter Pressure filling leaves 1.27CM headspace, required by can manufacturers for product expansions and potential warming during distribution. Our machine will not foaming and it can keep low DO in the cans. Counter pressuring filling does not create foaming during filling process. Adopts high precision buffing process and food grade 304 stainless steel liquid tank. It will equipped with CIP connector as customer's demand.
“MIC” Counter pressure can filler foaming with hot water or beer jet after filling to eliminate head space and exposure to atmosphere. In order to prevent the oxygen into the can's top position. Jet foaming is the practice used by high-standard breweries. We have tested with dissolved oxygen meter, our TPO is lower than 50PPB.
Aluminum lid seaming system
The “MIC” system is a mechanism actuated, cam-driven seamer with easily adjustable rollers that allow for precise adjustment to from seams that are within can-maker specifications. Seams are formed in under only a second, faster than any other system in its class. Through two past decade’s technology innovation and optimization, the result is revolutionary.
Mic 18-1 Parameters
Power |
1.5Kw |
Filling heads |
18piece |
Sealing heads |
1piece |
Production capacity |
1000-2500CPH based on 330ml |
Filling temperature |
0-4 ℃ |
Filling pressure |
Max 5bar/0.5Mpa |
Can diameter range |
Ф40-90MM |
Can height |
92-168MM |
Dimension |
1900*1300*1950mm |
Weight | 2100Kg |
More Model And Speed Click
Model |
MIC 12-1 | MIC 18-1 | MIC 18-6 | MIC 24-6 | MIC 32-8 |
Application | Beer, Carbonated Beverage, Gas Drinks, Cold Coffee, Sparking Water, Cider, Soda Water, Herbal Tea, Non-Carbonated Drinks And So On | ||||
Packing Type |
Aluminum Cans, Metal Cans, Tin Cans, Pet Cans Etc |
||||
Speed | 1000-2000CPH | 1000-2500CPH | 3000-6000CPH | 4000-8000CPH | 6000-10000CPH |
Filling Arrange |
180ml, 250ml, 330ml, 355ml, 440ml, 500ml, 8oz, 12oz, 16oz, 1L and so on (0.1-1L) |
||||
Power | 1.1kw | 1.5kw | 2.5kw | 3.5kw | 4.2kw |
Size | 1.8*1.3*1.95 (M) | 1.9*1.3*1.95(M) | 2.3*1.4*1.9(M) | 2.58*1.7*1.8(M) | 2.8*1.7*1.95(M) |
Weight | 1800KG | 2100KG | 2500KG | 3000KG | 3800(KG) |
Name |
Brand |
Buttons |
Schneider (France) |
Touch screen |
Siemens (Optional) |
AC Contactor |
Schneider (France) |
PLC |
Mitsubishi (Japan) / Siemens (Optional) |
Frequency changer |
Schneider (France) |
Air cylinder |
AirTAC (China) / FESTO (Optional) |
Solenoid valve |
AirTAC (China) / FESTO (Optional) |
Relay |
Omron (Japan) / Schneider (France) |
photoelectric sensor |
Autonics (Korea) / Omron (Optional) |
Proximity switch |
Autonics / Omron (Optional) |
