This drink bottling machine function is:
1. Automatic bottle sensing system and filling
2. No bottle no filling
3. Filling error is control within 1‰
4. Filling arrange : mini volume: max volume =1:10
5. Automatic filling volume correction system.
6. Can be customized for different bottle and caps.
7. Can be equipped with cleaning system.
This drink bottling machine filling system is made for cosmetics package food bottle medical products and chemical products, easy clean and changes, we have automatic piston opening for cleaning. it is a practical machine for production and clean, 24 hours runs none stops, hardly have machine break down once well adjusted.
Machine filling accuracy max is at 1%, from 100ML-1000ML, 1L-5L volume, and it is piston filling controlled by servo motor.
This drink bottling machine is mechanical transmission, controlled by servo motor, it is well developed machine, use life more than 15 years.
This drink bottling machine is guaranteed for one year and you can extent your guarantee easily by discuss with our sales.
Which you might be interested, under guaranteed, machine parts got broken by daily use, we will replace it once we are informed by free DHL.
The advanced drink bottling machine represents a paradigm shift in the beverage industry, empowering businesses to optimize operations, meet consumer demands, and deliver exceptional products. With its cutting-edge automation and unwavering commitment to precision, this machine offers a transformative solution for streamlining beverage packaging. By embracing this technology, you can elevate your production capabilities, enhance efficiency, and secure a competitive edge in the dynamic world of beverage manufacturing.
Edible oil filling filling head
Put the oil into the material cylinder, the three-way valve controls the piston to pump oil into the metering cylinder cylinder, then the piston moves up to send the oil to the filling pipe, and when the bottle enters the filling machine through the conveyor belt, the filling head moves down to fill.
This filling machine has eight filling heads (the number of filling heads can be customized to your needs)
Conveyor belt
The conveyor belt can be different sizes of bottles, beside the width between the two tubes can be adjust according to your packaging container, ensure smooth bottle safely from the conveyor belt moved.The sides of the conveyor belt are equipped with sensors that are automatically identified when the bottle comes or goes out to send a signal to the filling and screwed cover station.
Thank you for the reading this article,
you can also check video for:
Filling Head |
8 Heads |
Filling Volume Range |
50-1000ml(Use 1000ml Piston Cylinder) |
Production Speed |
≤1800 Bph basis on 1000ml bottle |
Voltage |
220v/380v |
Power |
3kw |
Suitable Bottle’s Diameter |
Ф40mm-Ф100mm |
Filling Error |
≤±1 |
Work Pressure |
0.55Mpa-0.65Mpa |
Size |
2000mm × 1400mm× 2500mm |
Weight |
1000kg |
Parts |
Brand |
Touch Screen |
Canada xinjie color |
PLC |
Schneider |
Solenoid Valve |
Taiwan Airtac |
Optoelectronic System |
OPTEX |
Micro Differential Pressure Switch |
Netherlands |
Servo Motor |
Taiwan TECO |
Air Source Treatment |
Taiwan Airtac |
Button and low voltage electric appliance |
Schneider |
Ball Screw |
Taiwan |
Reducer |
Taiwan VGM |
Switching Power Supply |
Taiwan Meanwell |
Material |
Contact with the material parts of the 316 materials, and the rest of the 304 stainless steel |
