MIC 18-18-6 Automatic Beer Bottling Equipment(2000-3000BPH)

E-mail: sales8@micmachinery.com
Mobile: 0086-13771181029
Whatsapp: 0086-13771181029
Wechat: 0086-13771181029
Shipment: exporting country
Customer reviews: click on

Video

INTRODUCTION
TECHNICAL PARAMETER
CONFIGURATION LIST
CUSTOMER REVIEWS

Automatic Beer Bottling Equipment is a kind of professional filling machine for beer production.
It is made of high quality SUS304 stainless steel. Main components are processed precisely by CNC machine tool. The machine adopts advanced photo electricity to detect running status. No bottle no filling.

A beer bottle filling machine is a specialized piece of equipment designed to fill beer bottles accurately and efficiently. These machines are commonly used in breweries, beverage plants, and other facilities where large quantities of beer are produced.

As a manufacturer of beer bottle filling machines, we provide a variety of machines to meet different production needs. Our machines are designed with advanced technology and made of high-quality materials to ensure durability and reliability.

Beer bottle filling equipment can be either automatic or semi-automatic. An automatic beer bottle filling machine is designed to fill a large number of bottles quickly and accurately. These machines are ideal for high-volume production facilities. On the other hand, a semi-automatic beer bottle filling machine requires some manual labor but is more affordable and suitable for small and medium-sized breweries.

Overall, a beer bottle filling machine is an essential piece of equipment for breweries and beverage plants that produce beer in large quantities. As a manufacturer of beer bottle filling machines, we offer a range of machines to meet different production needs, from small-scale breweries to large-scale production facilities. Our machines are designed to be efficient, reliable, and easy to operate, ensuring that our customers can produce high-quality beer with ease.

Washing Part

Washing part is mainly composed of washing pump, bottle clamps, water distributor, up turn-plate, guide rail, protection cover, spraying device, defrosting tray, rinse water take and rinse water refluxing tank.
The bottle is turned upside down and centered above a spraying nozzle which directs a stream of rinse water into the bottle. After the draining period the bottle is turned over to an upright position again.

Capping Part

Capping part is mainly composed of capping heads, cap loader (separated), cap unscrambler, cap drop rail, pressure regular, cylinder and also we need an air compressor as the auxiliary external equipment.
Cap distributing chute is equipped with a photocell switch to stop the capper when there is no cap inside the chute. The capper is equipped with inlet bottle detection switch.

Filling Nozzle	18 Heads
Water Rinse Nozzle	18 Heads
Capping Head	6 Heads
Filling Volume	0.25-1.5L
Filling Speed	2000-3000 Bottles/h (500ML)
Air Pressure	0.6Mpa
Air Consume	0.15m³/min
Washing Water Pressure	0.2Mpa
Washing Water Consume	Less Than 1T/h
Main Motor Power	2.2KW
Total Power	5KW
Size	2500mm1900mm2300mm
Total Weight	3500KG
Voltage	220/380V/50HZ (Can Be Customized)
Control	PLC+Touch Screen
Material	SUS 304

Name	Brand
Push Botton	Schneider France
Electromagnetic Contactor	Schneider France
Relays	Omron Japan
Frequency Converter	Mitsubishi or Siemens Japan
Air Cylinder	Air TAC Taiwan
Electromagnetic Valve	Air TAC Taiwan
PLC Control System	Siemens Germany
Touch Screen	Siemens Germany
Photoelectric Switch	DELIXI China
Proximity Switch	DELIXI China
Reducer	Zhejiang Duoli China
Sealing Motor	Zhejiang Duoli China
Baromter	Air TAC Taiwan
Bearing	Harbin China

Water Factor, Tirana Albania, 2012

Beer Canning Factory, Wales UK, 2017,03
