The machine adopts PLC control, according to the filling cup, fixed discharging mouth, the rest all operation can be finished on a touch screen. In addition to have common automatic piston filling machine advantages, also the widened the range of filling material. Such as filling material contains particles, long strips of solid content, also can be a very effective filling.
1. Available with standard conveyor or with pucks for unstable cups
2. Flexible design
3. Very fast and easy changeover of format size
4. Docking filling station model available
5. Anti-dripping filling nozzle
cup loading station
Put the finished cups into the cup loading station. When the machine receives the start signal, the cup loading station will automatically drop the cups to be filled into the mold accurately, which is convenient for later filling.
foil loading sucking disks
The device is designed to absorb the sealed tin foil film with a moderate suction force. When the cup reaches the desired position, the two pieces of foil are automatically absorbed and placed on the cup with precision. The working process is time-saving and stable
filling head
This machine adopts automatic piston filling, can ensure the precise filling you need filling quantity, the whole process without drip leakage, no waste of materials.
In short, we will try our best to provide you with satisfactory service,the following is our customer feedback:
Diameter |
1100*1100*1600mm |
Weight |
350KGS |
Power |
2 KW |
Voltage |
110V/ 60Hz 1P |
Air pressure |
0.6-0.8Mpa |
Capacity |
600-800 pcs/hour |
Air consumption |
0.6m³/min |
Heating type |
electrical heated |
Working position |
6 |
Machine frame |
SUS 304 |
Item |
Brand |
PLC |
OMRON |
Touch Screen |
WEINVIEW |
Motor |
DINGYI |
Magnetic Valve |
JELPC |
AC Contactor |
SCHNEIDER |
Temperature Control |
SIMP |
Relay, Circuit Breaker |
DELIXI |
Divider |
REP |
Pneumatic Component |
AKS |
