MIC-24-6 rotary type cooking edible oil can filling seaming machine adopts volumetric type quantitative filling system which is applicable for vegetable oil , cooking oil , olive oil, edible oil, sunflower oil, peanut oil etc liquid like oil products.
Features:
1.Volumetric type quantitative filling can ensure high precision filling, do not waste materials. To make the filling process is stable and high efficient.
2.The structural design of each part fully considers the health requirements, the filling cylinder,filling valve and parts in contact with the material are made of stainless steel 304, with good corrosion resistance.
3.This machine is equipped with a set of adjustment device, so that customers can fill 100ml~1000ml bottles without changing the measuring cup, only adjust the measuring cup capacity. No bottle no filling function.
4.The position turning block of the filling valve turns the position and opens the valve under the action of another cylinder. Cylinder backblowing anti-drip device.
5.It is mainly used for oil can filling and seaming. Its structure is advanced, stable, reliable, safe operation, convenient maintenance, the use of frequency conversion speed control, high production efficiency, is the ideal equipment for big and medium sized food and oil factory.
Oil Can Filling Machine: A Cost-Effective Solution for Filling and Packaging Lubricants and Oils
An oil can filling machine is a specialized piece of equipment designed for the efficient filling and packaging of various types of oils and lubricants in metal or plastic cans. These machines are commonly used by lubricant manufacturers and oil producers that require a cost-effective, reliable, and high-precision filling solution.
The oil can filling machine works by automatically filling the cans with a predetermined volume of oil or lubricant and then sealing them with a cap or lid. The machine can handle different types of oils and lubricants such as engine oil, gear oil, hydraulic oil, and industrial lubricants. It is also capable of filling a wide range of can sizes and shapes, making it highly versatile.
One of the main benefits of using an oil can filling machine is its efficiency. These machines can fill hundreds of cans per hour, which significantly increases the production output and reduces labor costs. Additionally, they ensure a high level of accuracy and consistency in the filling process, which helps to maintain the quality of the oil or lubricant.
Another advantage of using an oil can filling machine is its versatility. These machines can handle different types of oils and lubricants and can fill a wide range of can sizes and shapes, which makes them a perfect choice for lubricant manufacturers and oil producers that require a diverse range of packaging options. The machine can also be customized to fit specific production needs, further increasing its flexibility.
In conclusion, an oil can filling machine is an essential piece of equipment for lubricant manufacturers and oil producers that require a cost-effective, reliable, and high-precision filling solution. These machines offer a reliable and cost-effective solution for filling and packaging various types of oils and lubricants and provide a high level of versatility to meet different production needs.
Volumetric type quantitative filling system
Filling part working principle: this machine adopts non-contact quantitative filling. Open the measuring cup control valve, feed oil to the measuring cup according to the adjusted flow, and the cans is conveyed into the filling machine by the conveyor belt, screw and dial wheel. At the same time, the time control is used to close the measuring cup control valve after accurate measurement. After the filling process is completed, the cylinder acts to blow the last remaining oil from the valve port into the cans, so as to achieve the effect of no drip leakage. Then send to the seaming machine to complete the seaming.
Aluminum lid seaming system
The motor transmits the power to the main shaft through the transmission device, so that the turntable rotates. Because the central gear does not rotate, the rotary cap rotates because of the rotation of the gear of the rotary cap shaft. When the machine sealing, the cover through the automatic cover falling device, cover falling guide rail, there is a can into the cover plate, no can no cover, when the rotation of the cap side moving down, rotation (pressure) cap under the action of the CAM to complete the cover. Then by the drawing wheel into the can delivery
Liquid nitrogen doser
In order to extend the shelf life and freshness of the oil, we will suggest our customer to add this liquid nitrogen doser to work with filling machine.
Power |
4Kw |
Filling heads |
24piece |
Sealing heads |
6piece |
Filling volume range |
0.1-1L |
Production capacity |
4000-8000CPH based on 330ml |
Filling temperature |
Room temperature |
Can diameter range |
Ф40-90MM |
Can height |
92-168MM |
Air pressure |
0.6-0.8Mpa |
Air consumption |
0.8-1.0m³/min |
Dimension |
2600×1400×2500mmm |
Weight |
3000Kg |
Name |
Brand |
Touch screen |
Siemens (Germany) |
Buttons |
Schneider (France) |
AC Contactor |
Schneider (France) |
PLC |
Mitsubishi (Japan) / Siemens (Germany) |
Frequency changer |
Schneider (France) |
Breaker |
Schneider (France) |
Air cylinder |
AirTAC (China) / FESTO (Optional) |
Solenoid valve |
AirTAC (China) / FESTO (Optional) |
Relay |
Omron (Japan) / Schneider (France) |
photoelectric sensor |
Autonics (Korea) / Omron (Optional) |
Proximity switch |
Autonics / Omron (Optional) |
