Carbonated Beverage Filling Machine/Carbonated Beverage Production line Description: DCGF series 3-in-1 carbonated beverage filling mono-bloc is used in the PET bottle filling of gas containing beverage, such as Coco-cola, Pepsi-cola, Spirit drink etc. It is combined with bottle washing, filling and capping into one machine.
1. This series of filling machines are used in production of PET bottled carbonated beverage, such as carbonated water, sprite and so on.
2. This series of products are the integrated rinsing, filling and capping machine, suitable for producing various PET bottled carbonated beverage.
3. The main machine adopts advanced PLC control technology.
4. The key electric elements adopt international famous products.
5. We will give you the highest quality and the best service.
The plastic bottle soda filling machine is at the forefront of efficiency in the beverage industry. Designed to handle high-volume production, this machine fills plastic bottles with soda at impressive speeds, surpassing manual or semi-automatic methods. With its automated processes, the machine ensures consistent fill levels, minimizing variations and guaranteeing uniform product quality. Its high-speed capabilities empower manufacturers to meet demanding production targets while maintaining the meticulous nature of plastic bottle filling.
Filling Part
Filling part is mainly composed of filling barrel, filling valve (low temperature and isobar filling), filling pump, bottle hanging device / bottle pedestals, guide rail, elevating device, liquid indicator, pressure gauge, pressure regulator, etc.
Capping Part
Capping part is mainly composed of capping heads, cap loader (separated), cap unscrambler, cap drop rail, pressure regular, cylinder and also we need an air compressor as the auxiliary external equipment.Technical parameter | |
---|---|
Washing head | 32pieces |
Filling head | 32pieces |
Capping head | 10pieces |
Volume | 0.1-2L |
Production capacity | 8000-10000bottle/hr base on 500ml |
Suitable bottle height (mm) | 60-340 |
Suitable bottle diameter (mm) | Ø50 - Ø95 |
Power of main motor (kw) | 5.0 |
Water pressure (Mpa) | 0.25-0.3Mpa |
Shape dimension | 3400mm*2500mm*2300mm |
Weight | 10000kg |
Filling temperature | 5 degree |
Suitable bottle | PET bottle with crew cap |
1 |
Name |
Brand |
2 |
Push Button |
Schneider France |
3 |
Electromagnetic Contactor |
Schneider France |
4 |
Relays |
Omron Japan |
5 |
Frequency Converter |
Siemens |
6 |
Air Cylinder |
AirTAC Taiwan |
7 |
Electromagnetic Valve |
AirTAC Taiwan |
8 |
PLC Control System |
Siemens |
9 |
Touch Screen |
Siemens |
10 |
Photoelectric Switch |
Autonics |
11 |
Proximity Switch |
Autonics |
12 |
Reducer |
Zhejiang Duoli China |
13 |
Sealing Motor |
Zhejiang Duoli China |
14 |
Barometer |
AirTAC Taiwan |
15 |
Bearing |
Harbin China |
